SRK10CFV-4
END ITEM NO. : RWA002F050D
Recommendable Purchased Q't
y
10 30 50 100 500 1000
1-6 RKX 102A 001B PANEL ASSY,FRONT 1 1112
1 RKX 122A 001B PANEL,FRONT 1
2 RKX 435A 004 PANEL ASSY,AIR IN 1 1123
3 RKX 437A 001 FILTER,AIR 2 1112W315×H294.3(t2)
4 RKX 129A 013 CAP 2
5 RKX 129A 014 HOLDER,FILTER 2 1112
6 RKX 133A 001 PLATE,ORNAMENT 1 1112
7-27 RKX 435A 002 GRILLE ASSY,AIR OUT 1 1123
7 RKX 435A 003 GRILLE,AIR OUTLET 1
8 RKX 436A 001 FLAP(A) 1
UPPER
9 RKX 436A 002 FLAP(B) 1
LOWER
10･11 RKX 436A 003 LOUVER ASSY(R) 1 1122
10 RKX 436A 005 LOUVER 6
11 RKX 129A 008 PLATE,CONNECTING(R) 1
12･13 RKX 436A 004 LOUVER ASSY(L) 1 1122
12 RKX 436A 005 LOUVER 6
13 RKX 129A 009 PLATE,CONNECTING(L) 1
14 RKW 935C 200 COLLAR 6
15 RKX 129A 010 BRACKET,MOTOR(A) 1 1112
16 RKX 129A 011 BRACKET,MOTOR(B) 1 1112
17 RKX 129A 012 BRACKET,MOTOR(C) 1 1112
18 RKX 144A 001 LINK 1 1112
19 RKX 144A 002 CRANK(A) 1 1112
20 RKX 144A 003 CRANK(B) 1 1112
21 RKW 144A 204 CRANK(C) 2 1112
22 SSA 512T 052 MOTOR,STEPPING 3 1112FOR FLAP/LOUVER(R,L)
23 RKS 504A 100G HARNESS ASSY 1 1112FOR FLAP
24 RKS 504A 100 HARNESS ASSY 1 1112FOR LOUVER(R)
25 RKS 504A 100L HARNESS ASSY 1 1112FOR LOUVER(L)
26 SSA 423A 094 HOSE,DRAIN 1
27 SSA 326A 047 PLUG 1
28 RKX 111A 001 BASE ASSY 1 1112
29 SSA 511J 218 MOTOR,AC 1 1112FOR IMPELLER
30 SSA 431G 044 IMPELLER 1 1124
31 SSA 923C 114 BEARING,PLANE 1 1112
32 RKX 129A 005 COVER(MOTOR) 1 1112
33 RKX 032A 001 PLATE,INSTALLATION 1 1112
34 RKX 132A 001A LID 1 1124
35 SSA 913A 007A SCREW,TAP 4 4×14
NoteNo. Part No. Part Name RE.Q
- 34 -
