Mitsubishi SUZ-KA24NAH2 - Data; Standard Operation Data

11
OCH688A
7DATA
STANDARD OPERATION DATA
Representative matching SEZ-KD18NA4 SLZ-KF18NA PEAD-A18AA7 PEAD-A24AA7
Item Unit Cooling Heating Cooling Heating Cooling Heating Cooling Heating
Total
Capacity BTU/h 18000 21600 17700 19700 18000 21600 24000 25000
SHF – 0.82 – 0.71 – 0.80 – 0.77 –
Input kW 1.31 1.58 1.41 1.85 1.27 1.6 1.92 1.99
Electrical circuit
Indoor unit SEZ-KD18NA4 SLZ-KF18NA PEAD-A18AA7 PEAD-A24AA7
Power supply (V, phase, Hz) 230, 1, 60 230, 1, 60 230, 1, 60
Input kW 0.09 0.07 0.04 0.04 0.11 0.09 0.12 0.1
Current A 0.74 0.63 0.43 0.38 0.95 0.84 1.03 0.92
Outdoor unit
SUZ-KA18
NA(H)2
SUZ-KA18
NA(H)2
SUZ-KA18
NA(H)2
SUZ-KA24
NA(H)2
Power supply (V, phase, Hz) 230, 1, 60 230, 1, 60 230, 1, 60
Input kW 1.22 1.51 1.37 1.81 1.16 1.51 1.8 1.89
Current A 4.96 6.24 5.70 7.66 4.57 6.12 7.32 7.73
Refrigerant circuit
Condensing pressure PSIG 369 366 372 492 371 365 411 418
Suction pressure
PSIG 141 100 125 105 135 100 140 108
Discharge temperature °F 158 167 155 174 158 167 161 162
Condensing temperature °F 111 110 111 128 111 110 119 120
Suction temperature °F 56 41 46 34 57 41 51 35
Ref. pipe length ft. 25 25 25
Refrigerant charge (R410A) – 1.6 1.6 1.6 2.2
Indoor
unit
Intake air temperature
DB °F 80 70 80 70 80 70 80 70
WB °F 67 60 67 60 67 60 67 60
Discharge air temperature DB °F 57 101 56 108 56 103 56 101
Outdoor
unit
Intake air temperature
DB °F 95 47 95 47 95 47 95 47
WB °F 75 43 75 43 75 43 75 43
