Mitsubishi SUZ-KA24NAH2 - Suz-Ka24 Na(H)2.Th; Suz-Ka30 Na(H)2.Th; Suz-Ka36 Na(H)2.Th

31
OCH688A
SUZ-KA24NA(H)2.TH SUZ-KA30NA(H)2.TH SUZ-KA36NA(H)2.TH
-4 14 32 50 68 86 104
0
10
20
30
40
50
60
70
80
90
100
Temperature(°F)
Defrost thermistor(RT61)
Ambient temperature thermistor(RT65)
Outdoor heat exchanger temperature thermistor(RT68)
32 50 68 86 104 122 140 158 176
0
20
40
60
80
100
120
140
160
180
200
Temperature(°F)
Fin temperature thermistor(RT64)
Resistance(k )
Resistance(k )
Temperature (°F)
Discharge temperature thermistor (RT62)
5HVLVWDQFHN
0
100
200
300
400
500
600
700
800
32 50 68 86 104 122 140 158 176 194 212 230 248
Fin temperature
thermistor/RT64
(CN673)
Ambient temperature
thermistor/RT65
(CN672)
Discharge temperature
thermistor/RT62
(CN671)
Defrost thermistor
/RT61 (CN671)
Output to
drive outdoor
fan motor
(CN932)
Outdoor heat exchanger
temperature thermistor
/RT68 (CN671)
Fuse (F901)
T3.15AL250V
Fuse (F880)
T3.15AL250V
LEV (CN724)
Jumper wire for
changing defrost
setting (JS)
Jumper wire for
pre-heat control
setting (JK)
Fuse (F601)
T3.15AL250V
Signal of out-
door fan motor
(CN931)
R.V. coil (CN602)
208/230 V AC
208/230 V AC
260 - 370 V DC
IC700 (N)
IC700 (P)
LED
Heater (CN601)
208/230 V AC
