Ventilators
For pleasant driving 7-5
7
The mode selection and air flowing from the front ventilators
These symbols are used in the next several illustrations to demonstrate the quantity of air coming from the front ventilators.
: Small amount of air from the ventilators
: Medium amount of air from the ventilators
: Large amount of air from the ventilators
Face position Foot/Face position Foot position
Foot/Demister position Demister position
