SECTION I
I. GENERAL
1.0 SPECIFICATIONS:
Display Readable Temperature Range . . . . . . . . . . . . . . . . . . . . °F = -40° to 199.9°*
*Reading Limit Due to 3-1/2 Digit LCD Display on °F Range. °C = -40° to 150.0°
Guaranteed Temperature Calibration Range . . . . . . . . . . . . . . . . 32°F to 190°F
(and 0°C to 88°C)
Accuracy Over Calibration Range . . . . . . . . . . . . . . . . . . . . . . . . ±0.5°F (±0.2°C)
Accuracy Linear Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . ±1/8” (±3.0MM), Plus ±0.01%
of Total Tape Length, worst case
Minimum Detectable Tank Bottom Liquid Level . . . . . . . . . . . . . 3/8” (10MM)
Minimum Detectable Floating Product Level . . . . . . . . . . . . . . . . 1/8” (3MM)
Batteries for Intrinsically Safe Operation Only (supplied) . . . . . . . 9 Volt Eveready #522 or
Duracell MN1604
Battery Drain (Temperature Mode) . . . . . . . . . . . . . . . . . . . . . . . . 1.3 ma (In Air)
2.6 ma (In Fluid)
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1/2 Digit Liquid Crystal
Display 1/2” Character Height
Operating Temperature Limit of Liquid Crystal Display, -40°F to 176°F
Ambient Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40°C to 80°C
Storage Temperature Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -67°F to 185°F
-55°C to 85°C
Available Tape Length - Single Face Scale . . . . . . . . . . . . . . . . . . . 50 FT or 15 Meters
75 FT or 25 Meters
100 FT or 30 Meters
100 FT (10ths & 100ths)
120 FT (37 Meters)
Hazardous Environments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Certified Intrinsically Safe
BASEEFA and Factory Mutual
Gas Groups C&D
