EVA System: User Guide
20
Specifications
Item
Specification
Technical Data
Power Requirements
Charger Input Voltage
Frequency
Output
As rated by MicroUSB Charger
As rated by MicroUSB Charger
5V DC
Dimensions
Colposcope (HxWxD)
Lens
20.8cm x 7.8cm x 11cm (w/lens)
20.8cm x 7.8cm x 6cm (w/o lens)
93.1mm long x 30mm diameter
Weight
Colposcope
Lens
400g
108g
EVA System
Specifications
(For Samsung J5)
Working Distance
Magnification
Field of View
Depth of Field
225mm – 425mm
4.0X optical/17X with digital zoom
(at 250mm)
3.8X optical/16X with digital zoom
(at 450mm)
54mm (at 250mm) - 106mm
(at 450mm)
17mm (at 250mm) - 34mm
(at 450mm)
Operating
Environment
Ambient Temperature
Relative Humidity
Atmospheric Pressure
50°F (10°C) to 105°F (40°C)
95% max
70kPa to 110kPa
Illumination
Lamp type
Lamp voltage
6500K 3W LED
3.6V
