MobilSat Mounting Instructions – User Manual
Page 14 of 16
2.6 List of available satellites
In the following table is displayed the list of available satellites; positions 17-20 can be
customized via the Installer Menu
1-5
6-10
11-15
16-20
AMOS 3W
ATLANTIC BIRD 5W
EUTELSAT 7E
TURKSAT 42E
ASTRA 4.8E
ATLANTIC BIRD 8W
EUTELSAT 10E
SATELLITE 1
ASTRA 19E
ATLANTIC BIRD 12W
HISPASAT 30W
SATELLITE 2
ASTRA 23,5E
EUROBIRD 9E
HOTBIRD 13E
SATELLITE 3
ASTRA 28E
EUROBIRD 16E
THOR 1W
SATELLITE 4
3 Failures or malfunctions
In case of fault the display will show the symbol and the error description
The following table shows the most common causes of errors with the explanation and the
possible reason/solution.
Failure
Possible solution
The system does not power
up
 Check the fuse on the power line.
 Check that all cables are correctly plugged in
The antenna does not
performs automatic satellite
search
 Check that the direction toward South is free from obstacles
(building, mountains, trees, …)
 Check that in your location it is not necessary to compensate
the SKEW angle
 Check if you are in the area covered by the selected satellite
The antenna performs the
automatic satellite search
but the TV does not display
any signal
 Check that all cables are correctly plugged
 Check that the decoder works and is up to date
Display shows
”Serial line error”
 Detected improper connection between control unit and touch
screen display
Display shows
”Mechanical error”
 Detected mechanical malfunctions or electrical problems
between control unit and outdoor unit
Display shows
”Engine running”
 Antenna or inhibition function due to the engine running
