Mocka Kitchen - Integrating Internal Components; Step 17: Attach Panel [7] and Insert Panel [1]; Step 18: Attach Latches and Hinges

17
18
Slide panel [1] into panel [11] and attach with 1x screw (A).
Attach panel [7] to panels [1], [9] and [13] with 5x screws (A).
Tigthen all screws with a screwdriver.
Slide panel [5] onto shelf supports (K) on panels [7] and [11].
Attach 1x latch (H) to panel [2] with 2x screws (D).
Attach 1x hinge (E) to panel [2] with 2x screws (D).
Attach panel [24] to panel [10] with 2x screws (B).
Tighten all screws with a screwdriver.
