Mocka Kitchen - Final Hinge and Panel Attachments; Step 21: Mount Hinges and Panels; Step 22: Attach Hinges and Latches to Panel [4]

21
22
Place 1x hinge (E) into panel [9].
Insert hinge (F) into panel [13] and swing panel [3] down into hinge (E).
Attach hinge (E) to panel [3] with 2x screws (D).
Tighten all screws with a screwdriver.
Attach 1x hinge (F) to panel [4] with 2x screws (D).
Attach 1x latch (H) to panel [4] with 2x screws (D).
Attach panel [25] to panel [4] with 2x screws (B).
Tighten all screws with a screwdriver.
