13
14
Attach 1x latch (H) to panel [10] with 2x screws (D).
Attach 1x hinge (E) to panel [10] with 2x screws (D).
Attach panel [25] to panel [10] with 2x screws (B).
Tighten all screws with a screwdriver.
Place 1x hinge (F) into panel [16].
Insert hinge (E) into panel [19] and swing panel [10] down into hinge (F).
Attach hinge (F) to panel [10] with 2x screws (D).
Tighten all screws with a screwdriver.
D
10
25
D
D
D
B
B
E
H
F
E
16
19
E
F
D
D
10
10
F
10
10
16
19
Mocka Kitchen
8
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
Assembly Instructions
