2. Denition of Available Models
This operating manual refers exclusively to the following models, of our own manufacture:
MODBAR, Steam System
1 Steam Actuator Lever
2 Steam Wand
3 Extra Tap
4 Power Switch
5 Selector
6 Refresh Button
7 Pressure Gauge
8 Pressurestat
9 Water Inspection Window
10 Drain
11 Tap 1 Steam
12 Tap 2 Steam
13 Water Inlet
14 Power Inlet
15 Tap 1 Low Voltage
16 Tap 2 Low Voltage
17 Drain Tray Grate
Legend
Fig. 1 - STEAM System
2
4
7
14
Steam Tap
Steam Module
13
16
15
17
1
8
10
12
11
9
6
5
3
