English 15
Please read this operation manual carefully before operating the unit in order to correct and safe use
of the unit. Examine the entire sign or warning listed either pictures or written explanation.
DD 75 L
1. Install the dispenser on an even and
stable surface. Provide a minimum of 20
cm of distance from the wall.
2. Leave it for 1 hour to stabilize the
refrigerant.
3. Insert the pipe to the gallon and then plug
the cover to mouth of gallon.
4. Center the gallon and close the lower
cabinet door.
5. Connect the electrical cord to the outlet,
and turn on the red switch (heater) located
behind the unit. Ensure that the socket /
electric source has a grounding to prevent
electric leakage. And turn on the switch
located behind the unit.
6. For the first time to use, the inside of the unit must be cleaned. Press the hot water
and cold water. Make sure the water out of the tap both. After both the tap water out,
wait around 20 minutes, then remove gallons of storage and empty the water in the
unit by opening the drain cover. Make sure the power cord is unplugged from the
power source when the discard excess water.
To prevent the dispenser failling/wrobly can be adjusted for placement
using the bracket :
1-2. Loosen the screws on the bottom left or right corner as the picture
……shown.
3. If the bracket has been removed, and then instal the screws in the
.......bottom left or right corner of the dispenser.
4. Make a hole in the floor/surface suitable placement dispenser
5. Install the bracket screws on the floor to close.
6. Tighten screws.
DD 07 W
1. Place the dispenser is in a flat and stable.
2. Install gallons of water in the right position.
3. Install gallons of water in the right position.
4. Press / hot water tap (red) until the water flowing out of the faucet.
5. the power cord into a socket. Then turn on the red switch (heating)
located at the rear of the unit.
6. When the water in gallon is up, turn off the switch red (heating)
before replacing it with a new one.
