3.B Installation in the Kitchen Cabinet
This product can be installed between the kitchen set, as long as the part of the kitchen
cabinet which is in contact with the unit must be heat resistant to high temperatures over 90°
C, including the walls on the sides and the back of the unit must be heat resistant to high
temperatures over 90 ° C.
1. The distance of the side wall to the unit, which the height of the wall exceed the unit, at least 50
mm.
2. Distance from the cook top surface to the cabinet or the object above the cook top at least 750
mm.
4.A. Method for Using Top burner
A.1 How to ignite the top burner:
1.a One hand ignition system, to ignite the burner simply by pressing
and turning the Knob. (Figure 3.a).
1.b For top burner equipped with leakage safety device, hold the knob
for around 7 seconds after pressing it and the fire is burning in
the burner. If you release the pressure before the specified period,
the fire will automatically be put out. Stoves equipped with
leakage safety device can be identified visually as shown in
Figure 4.
1.c To intensify or reduce the flame in the burner, turn the knob to
face the small flame or big flame icons (Figure 5).
