MODENO Venice - Assembly Instructions; Battery Installation; Propane Tank Seating

9 / 20
Make sure the gas supply system is turned to “OFF”.
Install a AAA battery as shown in the diagram below.
Battery is not included.
_
+
1. Place the tank seat （Sold Separately) on the ground and place a 20 lb.
propane tank into the tank seat.
2. Tighten down the screw on the side of the tank seat to secure the
propane tank.
1
2
ASSEMBLY INSTRUCTIONS
1
2
