FR-W200120
18
A
B
C
Air-Gap
Switch*
11
Controlling the Fan
Your fan is pre-paired. If you need to pair your fan refer to step 17.
A: Light On/O, Bright/Dim +/- B: Fan On/O, Fan Speed +/-
C: Reverse Button (Summer and Winter Modes)
Air-Gap Switch: Pull tab to power o in case of emergency.
Not necessary for normal fan operation (only included with
wall control).
Summer Mode
(Counter-Clockwise)
Winter Mode
(Clockwise)
16 17
Pairing
Press and hold buttons
for 10-15 seconds.
Wall Control
* Air-Gap Switch only included
with wall control
Remote
Control
Unpairing
To purge, press and hold
buttons for 4 seconds.
NOTE: Your fan features 6 speeds. An audible tone will indicate when
the speed is increased or decreased. When the fan has reached the
minimum/maximum speed level the fan will beep twice.
NOTE: Pairing must be completed within 3 minutes of power being
applied to the fan receiver.
