Modern Forms Renegade - Luminaire Module Completion; Luminaire Module and Light Cover Attachment

19FR-W2001
Adapter
Plate
Screws
LED Luminaire Module
Connection Plugs
Acrylic
Shade
Metal Light Cover
14 15
Installing the Luminaire Module 10
1. Install metal light cover as shown.1. Secure the luminaire module with the 3 screws to the
adapter plate.
2. Install glass shade without over-tightening.
