FH-W2004
TipTop Instructions8
Package Contents
6. LED Module
F3IN-120V-R1-30
7. PC Shade
RPL-F2004-GLA
8. Receiver
F-R3-2004-0**
9. Remote Control
F-RCBT-WT
Hardware Bag
RPL-F2004-PARTS
1. Fan Blade
RPL-F2004-**-BD-**
2. Mounting Bracket
RPL-F2004-HGR-**
3. Decorative Trim Ring
RPL-F2004-TRIM-**
4. Motor Housing
5. Adapter Plate
** denotes finish code of fan /blade sweep of fan
Before discarding packaging materials be certain all parts have been removed.
Place the parts from the hardware bag into a small container to keep them from being lost.
D: Wire Connectors (8)
E: Attach the Mounting Bracket to the
Ceiling
3/16”x15mm Slotted Pan Head Screw (4)
F: Attach the LED to Adapter Plate
#8*1” Phil Truss Head Screw (4)
A: Junction Box
#10x38mm Pan Head Phillip Screws (2)
Ø5*14*1mm Flat Washer (2)
3/16" Star Washer (2)
B: Blade
3/16*12 mm Philip washer head screw (10)
C: Safety Cable
Φ6.5x19x2mm Flat Washer (1pc)
3/16”(Φ5.2x8.4x1.0mm) Spring Washer (1)
#10x76mm Pan Head Phillip Wood Screws (1)
• Part A
• Part B
• Part C
• Part D
• Part E
• Part F
Hardware Bag
Found with the receiver
To Next Page
