Modular Closets DOUBLE HANGING UNIT - Preparation and Parts Identification; Parts List; Tools Required

A B
D
C
E
FRONT FRONT
FINISHED EDGE
FINISHED EDGE
C
D
E
F
G
H
I
J
Set Shelf (Qty 2)
Rear Cleat (Qty 2)
Hanging Rod (Qty 2)
Rod Bracket (Qty 4)
Cam Post (Qty 12)
Camlock (Qty 12)
Screw, 5/8" (Qty 4)
Screw, Square Drive, 2.5" (Qty 4)
A
B
Left Side Panel
Right Side Panel
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
DOUBLE HANGING UNIT
J
G
H
I
PARTS LIST
BOX 1 BOX 2
Level
Stud Finder
Drill, 3/32" bit size
Phillips Screwdriver
Drill Bit, Square,
#2
TOOLS REQUIRED
(not included unless noted)
1A
1B
1.1
1.2
Lay parts out on a protective surface to
prevent damage. Tip: Spread out the
cardboard packaging to use as a
protective surface.
Inventory parts against the Parts List. Make
sure all parts are present before proceeding.
F
