MOHAWK MODEL LMF
-
12
4
LMF-12 PACKING LIST
*** ALSO SEE DRAWINGS MAN511, MAN512, & MAN513 IN PARTS MANUAL ***
ORDER
NUMBER
PART
NUMBER
PART
DESCRIPTION
QTY.
012-012-056 PARTS BOX #1CONTENTS
1
623 007-007-075 SHIM BAG 1
040 012-012-047 LIFTING PAD 4
627 012-012-058 SMALL PARTS BAG 1
145 012-012-113 SWING ARM PIN 4
297 600-670-009 WEJ-IT ANCHOR (3/4 X 6 1/4) 16
482 600-690-008 LOCK NUT, 1-3/8-12 NF 8
460 601-170-008 HUBBLE CONNECTOR (FEMALE) 1
112 601-630-001 SPRAY PAINT (RED) 1
113 601-630-002 SPRAY PAINT (YELLOW) 1
012-010-055 MANUAL ASSEMBLY (INSTALLATION) 1
627 012-012-058 SMALL PARTS BAG CONTENTS
171 600-640-019 BOLT, 1/4-20 X 1-1/2 10
258 600-690-005 LOCK NUT, 1/4-20 NC 10
259 600-710-004 WASHER, 1/4 SAE FLAT 4
021 601-310-005 BREATHER CAP 1
094 601-420-011 FITTING, DOUBLE MALE UNION # 6 JIC 4
409 601-710-001 DOUBLE LINE CLIP 6
600-710-006 WASHER, FLAT, FENDER, 5/16 ID X 1 ½ OD 6
623 007-007-075 SHIM BAG CONTENTS
633 600-740-001 SHIM, 1/16 (BLUE) 8
634 600-740-002 SHIM, 1/8 (RED) 8
635 600-740-003 SHIM, 1/4 (BLACK) 8
012-012-057 PARTS BOX #2 CONTENTS
057 012-012-151 HEIGHT ADAPTER (7 1/2 INCH) 4
047 018-000-105 HEIGHT ADAPTER (10 INCH) 4
046 018-000-106 HEIGHT ADAPTER (5 INCH) 4
