TROUBLE SHOOTING, CONTINUED
POSSIBLE CAUSE SOLUTION
RAISING UNEVEN, CONTINUED
SHOP FLOOR UNEVEN USE SPECIAL LIFT PADS. SEE FIGURE 10.
DIVERTER VALVE REMOVE BLEED LINE FROM THE TOP OF THE OFF SIDE CYLINDER AND CAP
USING MOHAWK PART # 601-420-001. IF THE UNIT CONTINUES TO DRIFT DOWN
THE DIVERTER PULL VALVE WILL NEED TO BE CLEANED OR REPLACED.
BLEEDER VALVE REMOVE BLEED LINE FROM THE TOP OF THE OFF SIDE CYLINDER AND CAP
USING MOHAWK PART # 601-420-001. IF THE UNIT NO LONGER DRIFTS DOWN
THE BLEEDER VALVE WILL NEED TO BE SERVICED OR REPLACED..
MAIN SIDE CYLINDER PERFORM HYDRAULIC SAFETY CHECKS. CHECK FOR INTERNAL HYDRAULIC
LEAKS
SLOW DRIFT DOWN
SAFETIES NOT ENGAGED RAISE UNIT TO RE-ENGAGE SAFETIES. THEN LOWER UNIT ONTO SAFETIES.
POWER UNIT LOWERING VALVE
CONTAMINATION
BACK FLUSH POWER UNIT: PULL DOWN ON THE LOWERING HANDLE, AND
THEN ENGAGE THE UP BUTTON AT THE SAME TIME. RUN UNIT APPROX. 10
SECONDS
DIVERTER VALVE REMOVE BLEED LINE FROM THE TOP OF THE OFF SIDE CYLINDER AND CAP
USING MOHAWK PART # 601-420-001. IF THE UNIT CONTINUES TO DRIFT DOWN
THE DIVERTER PULL VALVE WILL NEED TO BE CLEANED OR REPLACED.
BLEEDER VALVE REMOVE BLEED LINE FROM THE TOP OF THE OFF SIDE CYLINDER AND CAP
USING MOHAWK PART # 601-420-001. IF THE UNIT NO LONGER DRIFTS DOWN
THE BLEEDER VALVE WILL NEED TO BE SERVICED OR REPLACED..
EXTERNAL HYDRAULIC LEAKS
NOTE: TIGHTEN ALL FITTINGS PER SPECIFICATIONS
MAIN SIDE CYLINDER THOROUGHLY CLEAN THE CYLINDER. VERIFY LEAK ORIGIN. FITTINGS ARE
TO BE TIGHTENED PER SPECIFICATIONS
OFF SIDE CYLINDER THOROUGHLY CLEAN THE CYLINDER. VERIFY LEAK ORIGIN. FITTINGS ARE
TO BE TIGHTENED PER SPECIFICATIONS.
BAD FLAIR OR FITTING REMOVE THE HYDRAULIC LINE AND INSPECT FLAIR AND FITTING FOR
DEFORMATION. REPLACE IF NEEDED.
BAD O-RING (O-RING TYPE FITTINGS) CHANGE O-RING
LOOSE PIPE FITTING REMOVE, RESEAL, AND RE-INSTALL FITTING.
SEAL ALL PIPE FITTING CONNECTIONS WITH THREAD SEALANT MOHAWK
PART # 601-610-002 NOTE: DO NOT USE TEFLON TAPE.
MECHANICAL LOCK HARD TO PULL
FLIPPER STICKING ONTO LOCK BAR APPLY A SMALL AMOUNT OF LUBRICANT TO THE LOCK BAR WHERE THE
FLIPPER RIDES. (DO NOT USE HEAVY GREASE)
