MoJack PRO Lift
7
Assembly Instructions
STEP 1
Remove MoJack PRO from package.
Inventory items to be certain all parts and hardware
are present. If any parts or hardware are missing,
please contact MoJack at 1-877-575-3173 or
email us at parts@themojack.com.
STEP 2
Assemble the Wheel to the Base
by inserting Cap Screw and Nylock Nut
and tighten. Repeat with second Wheel.
Note: Do not over tighten Nylock Nut.
Base
3
4 3
13 14
Wheel
4
Nylock Nut
14
Cap Screw
13
Attach the Tower to the Base
using Cap Screw and Nylock
Nut as shown.
Note: Do not over tighten Nylock Nut.
STEP 3
Cap Screw
15
1 3
15
14
Base
3
Nylock Nut
14
Tower
1
Cap
Screw
Hole
