Page 6 of 20
E Rev. G/ 09/2006
Lifting capacity (max):
160 kg
Lifting height (along column):
850 mm
Height legs:
Max 100 mm
Measurements:
1070 x 610 x 1280 mm (LxWxH)
Measurements in illustrations below are in millime-
tres.
Technical data QR1
Material:
Aluminium lifting column
Steel chassis and suspension
Lifting motor:
12 V DC w/worm gear
Linear worm screw with trolley
Weight, total:
Incl. battery: 30 kg
Battery:
14,4 V NiCd 1,9 Ah or 14,4 V NiMH 2,2
Ah, Molift PowerPac
Number of lifts (75 kg, 500 mm up/down):
Ca. 40
