22
Technical Data
Desktop size (corpus) T7: 115 x 75 x 9 cm
Desktop size (corpus) T7 XL: 150 x 75 x 9 cm
Desk height (infinitely adjustable):
without adaptor 56 - 118 cm
with adaptor (optional) 66 - 128 cm
Drawer internal dimensions:
T7: W 44,0 / D 30 / H 4 cm
W 35,5 / D 30 / H 4 cm
T7 XL: W 44,0 / D 30 / H 4 cm (2x)
W 12,5 / D 30 / H 4 cm (2x)
Max. drawer load: 6 kg
Max. loading capacity T7: 60 kg
Max. loading capacity T7 XL: 50 kg
Lifting speed: 38 mm / s
Noise level: < 60 dB(A)
Temperature range for operation: 0° bis +30° C
Temperature range for storage: -40° bis +50° C
Humidity for operation: 5% to 85% (non-condensating)
Humidity for storage: 5% to 90% (non-condensating)
Protection class I
IP class IP 20
Max. duty cycle: 10% ( 2 min. on / 18 min. off )
Nominal voltage: 220 - 230 V / 50 - 60 Hz
Drive / control 288 W
Power-Management (optional), total maximum load:
IEC type »F« (e.g. Germany, ...):
IEC type »V« (e.g. France, ...):
IEC type »G« (e.g. U.K., ...):
IEC type »L« (Italy):
IEC type »J« (Switzerland):
IEC type »I« (e.g. China, ...):
23
EC Declaration of Conformity
max. 3200W
max. 3200W
max. 2600W
max. 2200W
max. 2300W
max. 2000W
WEEE-Reg.-Nr.
DE 78284755
