Monacor MPX-2SC - Specifications

4 Specifications
Inputs
MIC: . . . . . . . . . . . . . . . 1 mV/600 Ω
PHONO (Mag.): . . . . . . 3 mV/50 kΩ (RIAA)
LINE: . . . . . . . . . . . . . . . 150 mV/100 kΩ
Outputs
MASTER: . . . . . . . . . . . 1 V, 8 V max.
REC: . . . . . . . . . . . . . . . 1 V, 8 V max.
Frequency range: . . . . . . . 20–20 000 Hz
THD: . . . . . . . . . . . . . . . . . 0.1 %
S/N ratio: . . . . . . . . . . . . . 65 dB
Headphones output: . . . . . ≥ 8 Ω
Talkover: . . . . . . . . . . . . . .
- 12 dB
Power supply: . . . . . . . . . . 230 V~/50Hz/6VA
Dimensions (W x H x D): . . 220 x 70 x 190 mm
Weight: . . . . . . . . . . . . . . . 2.2 kg
According to the manufacturer.
Subject to technical change.
