Fig. 5
R right
L left
9
Pedal marked R (Right) is to be assembled on the right hand
side of the cycle (the chain wheel side). The pedal axle has a
right hand thread and must be threaded onto the crank
clockwise. Tighten firmly. See fig 6.
Pedal marked L (Left) is to be assembled on the left hand
side of the cycle. The pedal axle has a left hand thread and
must be threaded onto the crank counter clockwise. Tighten
firmly. See fig 5.
NOTE! Check now and then that both pedals are still firmly
tightened. If not the threading in the pedal arms will be
damaged.
Also check that the pedal arms are firmly tightened on
the crank axle. If nessecary tighten.
