First check the brake belt tension. If the belt is too
tight loosen it a little by moving the force indicator to
about 4 kp and hold it there for a few seconds. Then
the force-adjusting servo will loosen the belt tension.
To be sure that indicator positions are correct, do a
calibration. See ”Electronic calibration”.
Press the switch(2) to turn off the power, see 1. fig:
Connections.
Adjust the scale mechanically so that 0-index on 2.
the scale and indicator are in line.
Move the indicator to 6 kp and hold it there.3.
Turn on the power again. The green LED on the 4.
lower left side of the bike is lit up when there is
power to the bike.
Hold the indicator at 6 kp until two beeps are 5.
heard.
Move the indicator to the settings that 6.
correspond with the type of external unit you are
connecting to:
0 = mode for use with PC or hand unit.
1 = mode for Siemens Megacart ECG
2 = mode for other ECG devices, alt 1.
3 = mode for other ECG devices, alt 2.
7. Hold at this position until two beeps are heard
and after that, move the indicator to 0 again.
The system will now restart in chosen mode.
Setting of command type (PC or ECG device)
From program version R15
Fig: Connections
1) Power connector
2) Serial port connection, external unit
3) Switch (on/off)
Alt. 1: ECG, Ergoline compatible command set,
requested load value.
Alt. 2: ECG, Ergoline compatible command set,
current load value.
Fig: LED (1)
(Left side in front of
rear support tube.)
What command type is set
Connect power to the bike and switch the power
switch to ”on” position without moving pendulum.1
beep = mode for PC or terminal, 2 beeps = mode for
ECG Siemens Megacart, 3 beeps = mode for other
ECG devices, alt 1 and alt 2.
Connection to controller
