Levelling your Loudspeakers
Carefully turn your loudspeakers over and position them in your desired locations.
Take the nylon washer and large locking nut (found in the packing end cap) (Fig. 4) and
place the washer over the threaded body of the foot assembly, followed by the locking
nut. Fig. 5. Do not tighten it all the way up just yet.
Place the spirit level (found in the Monitor Audio Tool Box) on top of your loudspeaker
to see if it is level. Adjustment (if required) is achieved using the Allen (hex) key to
change the height of the foot assembly until the loudspeakers are level. When you are
satisfied, tighten the locking nut.
Fig. 4.
Fig. 5.
8.
