Specication
Amplifier Output 600 Watts (RMS) 1200 Watts (Peak)
Crossover (Low Pass) 40Hz - 160Hz
Variable slope characteristic from 6 – 54dB/Octave
Sub-Sonic Filter (High Pass 16, 25 & 31Hz
Variable slope characteristic from 6 – 54dB/Octave
EQ 4 x Preset
1 x User Set
Equalisation Graphic 10 Band Equaliser.
± 6dB in 0.5dB steps
Digital Volume Level -80 – 0dB in 1dB Increments
Auto Sensing Input Line Level >5mV (RMS)
Requirements 5 – 25 minutes, user adjustable.
Cabinet Specification Sealed Cabinet with 25mm M.D.F construction with critical internal bracing. Sealed
amplifier compartment.
Amplifier Classification Class- D amplifier, with SMPSU (switch mode power supply) and DSP control
Driver Compliment 1 x 12” C-CAM® sub-woofer driver featuring triple suspension and 4” long throw voice coil
Dimensions Millimetres - 390 x 390 x 420 (H x W x D)
Inches 15 3/8 x 15 3/8 x 16 9/16
All dimensions excluding grille and feet
Weight (unpacked) 28 Kg (61.5lbs)
Mains Input Voltage:- 100 -120Vac, 220 - 240 Vac
(Automatically selected)
Fuse Type For countries with 220 – 240Vac supply use: 4A/250V 20MM UL/VDE
For countries with 100 – 120Vac supply use: 8A/250V 20MM UL/VDE
Trigger Input 3.5mm Jack input, +12Vdc = On State
Code System for All in One
Remote Controls NEC SH6122
C-CAM
®
is a registered trade mark of Monitor Audio Ltd
monitoraudio.co.uk
11
