5. Power Mode Switch with On-Auto-Off Facility

The Power Mode Switch has three positions: ‘On’–‘Auto’–‘Off’. When the switch

is in the ‘Off’ position the subwoofer will not function. In the ‘Auto’ position the

subwoofer will automatically switch on when an input signal is received. It will

remain on. If no signal is received foraround 15-20 minutes, the RS W12 will then

switch into standby mode until a signal is received once more. With the switch in

the ‘On’ position, the subwooferis permanently switched onunder allconditions.

6. RCA Line Level Inputs (Left & Right)

This is the only method of signal input connection to the RS W12. When using a

stereo amplifier system, connection can be provided by a pair of high-quality

signal cablesfrom the pre-out section of an amplifier. If a digital A/V processor or

A/V receiver/amplifier is to be used, a single cable can be connected from the

‘sub out’ or LFE connection on the amplifier to the RCA input connection on the

RS W12 labelled ‘R’. The RCA input marked ‘L’ in this case will remain unused.

Note: - cable lengths should not exceed 10 metres to avoid interference from

other electrical appliances.

7. RCA Line Level Outputs (Left & Right)

RCA line level outputs are provided in order to use other sub-woofers in

conjunction with the RS W12 by ‘daisy chain’ type connection. The outputs are

link outonly connections and donotprovide any form of filtering.

8. Warning Information

The followingwarning symbols arefound ontheamppanel. The meanings are:

This lightening flash with an arrow headsymbol,within an

equilateral triangle,is intendedtoalert the user to the

presence of uninsulated “dangerousvoltage”within the

products enclosurethatmay beof sufficientmagnitudeto

constitutea riskof electric shock to the persons.

Waning: To reducethe riskof electric shock, do not

removecover (or back) nouser-serviceable parts

inside. Refer servicingto qualifiedservicepersonnel

This exclamation point within an equilateral triangleis

intended toalert the userto presenceof important

operatingmaintenance (servicing)instructions in the

literature accompanyingthe appliance

Monitor Audio RS W12 User Manual
