Monitor Audio SILVER RXW-12 User Manual

monitoraudio.co.uk 11Silver RXW-1210
SPECIFICATION
Low frequency limit:- 27Hz (EQ1) 21Hz (EQ2)
Upper frequency limit:- 40 – 120 Hz Variable
Low pass filter alignment:- Active 4th order 24db/octave (two-stage filter)
Cabinet Specification: - Sealed Cabinet of 25mm M.D.F construction with internal
bracing
Amplifier Output:- 500 Watts (RMS) 1000 Watts (Peak)
Amplifier classification:- Class- D Digital amplifier
Driver compliment:- 1 x 12” C-CAM
®
subwoofer driver featuring triple suspension
and 3” long throw voice coil
Dimensions:- Cabinet: 340 x 340 x 380mm
(H x W x D) 13 3/8 x 13 3/8 x 14 15/16 Inches
Inc Amp and Driver: 340 x 340 x 410mm
13 3/8 x 13 3/8 x 16 1/8 Inches
Weight (unpacked):-
Input Impedance: - 20K Ohms
Mains input voltage:- 110 - 120 Vac / 220 - 240 Vac 50/60Hz
(Electronically Auto selected)
C-CAM® is a registered trade mark of Monitor Audio Ltd
TROUBLE SHOOTING
Should you experience any technical, or set-up problems with your subwoofer please check the
Trouble Shooting Guide below:
My subwoofer will not turn on/no power.
• Is the LED illuminated on the back of the unit?  If not, then check your mains lead is
properly connected both at the subwoofer and at the mains outlet. Also check the fuse of
the mains plug (where fitted) and also the fuse in the subwoofer. See page 6 & 8 for further
information on changing the fuse and it’s location.
• IstheLEDonthebackred?Ifso,youhavepowergoingtotheunit.Itcouldbethatthere
is no signal, or the 12v trigger is connected and the source not turned on (see below).
• Haveyougotthe12vtriggerconnected?Ifso,thesubwooferwillnotpowerupuntilthe
source is powered up.
• Hasitgotasignalgoingtoit(12vtriggernotbeingused)?Ifso,isthePowerModeSwitch
intheAutoorOnposition,andthesignalsourceisturnedon?Tryadjustingthevolume
level of the source.
If it still does not turn on/ power up, please contact your local dealer/ distributor or Monitor Audio
immediately.
No sound from subwoofer.
• IstheLEDonthebackredorgreen?Ifitisred,thentheunithasn’tactuallyturnedon.
See above suggestions. If it is green, then your unit is powered up and turned on. Check
further suggestions below.
• Arethesignalleadsconnectedcorrectly?Checkthese.Ifpossible,checkwithasecond,
known to be working set.
• Isthevolumeleveljustverylow?
If it still does not output a signal, please contact your local dealer/ distributor or Monitor Audio
immediately.
RXW12 manual.indd 10-11 18/08/2009 10:04:08
