Silver Series10
Connecting Speaker Cables
Bare Wire Connection
Unscrew the binding posts and pass
the bare wire through the through-hole
and tighten the binding post to clamp
the wire in place.
Banana Plugs
Remove the red and black plastic plugs
from the terminals and insert the banana
plugs into the holes that are revealed.
A knife blade of flat blade screwdriver
may be required to gain purchase on
the plugs.
Single Wire
Connect the banana plugs/ bare wire to
the terminals. Connect to either the top,
bottom or diagonally (experimentation
is advisable to achieve the preferred
results).
Leave the terminal links in
place.
Bi-Wire/ Bi-Amp
Connect the banana plugs/ bare wire to
the top and bottom terminals (positive
to positive and negative to negative).
The terminal links MUST be
removed.
