12.0 BULB REPLACEMENT
In the event of a bulb failure, Instructions on how to change a bulb are as follows: -
1. Ensure oven is isolated from mains supply and allow to cool.
2. Remove the left hand tray rack by unscrewing the fixing knob at the front and lifting
the rack up slightly to disengage the back locator. (See illustration, section 7.0).
3. Remove the four fixing screws and take glass, frame and gasket off lamp unit.
4. Remove the bulb by pulling in the direction of the arrow shown below and replace
with a new bulb.
5. Refit glass front, taking care that the gasket is in position around stainless steel frame.
6. Re-connect oven to the power supply and test.
DO NOT TOUCH NEW BULBS WITH BARE HANDS.
USE A CLOTH OR GLOVES TO STOP ANY MARKS THAT WILL
CAUSE HOT SPOTS AND PREMATURE BULB FAILURE.
