Bx oven ECO HAL range inc condenser and spares 24/01/13 RAC
9.0 MAINTENANCE
• Check for frayed or bare cables.
The machine must not be used if frayed or bare cables are visible.
• Follow cleaning instructions.
10.0 STEAM SYSTEM MAINTENANCE
• If it is noticed that the steaming operation has deteriorated, perhaps due to hard water
scaling, please contact your oven supplier
12.0 STEAM SYSTEM MAINTENANCE
11.0 BULB REPLACEMENT
In the event of a bulb failure, Instructions on how to change a bulb are as follows: -
• Ensure oven is isolated from mains supply and allow to cool.
• Remove screws (4 per light) and take glass, frame and gasket off lamp unit.
• Remove bulb by pulling in direction of arrow and
replace with new bulb.
• Refit glass front, taking care that gasket is in position around stainless steel frame.
Re-connect oven and test.
SCREWS
Pt No.B721-67-008
Pt No.B721-67-010
Pt No.B721-67-009
DO NOT TOUCH BULBS WITH BARE HANDS.
USE A CLOTH OR GLOVES TO STOP ANY MARKS THAT WILL
