Mono Bx OVEN

Bx oven ECO HAL range inc condenser and spares 24/01/13 RAC
50
PART 1
/ SECTION 3
–
10 TRAY
-
COOLING FAN AND DAMPER
DAMPER
SOLENOID L/H OVEN
B749-83-003
DAMPER SOLENOID R/H OVEN B749-83-004
PART 17
REAR FAN UNIT
B869-75-018
PART 34
REAR FAN UNIT FUSE
B842-85-025
PART 35
AUX. POWER OUTLET FUSE
B842-85-039
PART 37
PART NUMBERS REFER TO DRAWING M1500E25-75100 IN ELECTRICAL MANUAL
DAMPER BRACKET
150
-
02
-
01000
COUPLING
158-02-00600
FG150
