Bx oven ECO HAL range inc condenser and spares 24/01/13 RAC
The condenser can be fitted to any Bx oven or stacked Bx ovens as required.
With thermostatic control it can be adjusted to operate in most ambiant temperatures.
Simple water conection (washing machine type fitting) and a hose to drain are all that is
required to operate efficiently.
Steam is drawn from the fluepipe of the oven through a thermostatically controlled water
cooled chamber and condenses to drain away.
When the cooling water reaches a set temperature it is automatically replaced with cold
water to keep the condensing process as efficient as possible.
INTRODUCTION
THERMOSTAT CONTROL
WATER SOLENOID
THERMOSTAT
HOSE
FAN
TO DRAIN
