Design Guide
THE INSTALLATION SPACE
Water And Electrical Locations
7KHRSHQLQJPXVWEHSUHSDUHGZLWKWKHHOHFWULFDO
and the cold water supply located as shown.
The cutout depth must be 24”
7KHUHIULJHUDWRUZLOOSURMHFWIRUZDUGVOLJKWO\EH\RQG
adjacent cabinetry, depending on your installation.
Cutout depth beneath a soffit:
When installed beneath a soffit, the soffit cannot
H[FHHGWKHµLQVWDOODWLRQGHSWKVKRZQ7KHWRSFDVH
trim overlaps the bottom of the soffit.
Additional Specifications
$YROW+]RUDPSSRZHUVXSSO\LV
required. An individual properly grounded branch
circuit or circuit breaker is recommended. Install
a properly grounded 3-prong electrical receptacle
recessed into the back wall. Electrical must be
located on the rear wall as shown.
NOTE:*),JURXQGIDXOWLQWHUUXSWHULVQRW
recommended.
7KHZDWHUOLQHFDQHQWHUWKHRSHQLQJWKURXJK
WKHIORRURUEDFNZDOO7KHZDWHUOLQHVKRXOGEHµ
2'FRSSHUWXELQJRU*(6PDUW&RQQHFW
kit between
the cold water line and water connection location,
long enough to extend to the front of the refrigerator.
Installation of an easily accessible shut-off valve
in the water line is required.
DIMENSIONS AND CLEARANCES
* Shipping height.
The refrigerator can
be adjusted to fit
into a cutout that
is 83-1/2” min. to
84-1/2” max. height.
Note that the top
case trim at the
front is 1/2” higher
and will overlap
upper cabinetry or
soffit. Use leveling
legs and wheels
for a maximum 1”
height adjustment.
Product Clearances
7KHVHUHIULJHUDWRUVDUHHTXLSSHGZLWKDSRVLWLRQGRRU
VWRS7KHIDFWRU\VHWGRRUVZLQJFDQEHDGMXVWHG
to 90° if clearance to adjacent cabinets or walls
is restricted.
3
*The finished cutout width must be:
35-1/2” for 36” models
41-1/2” for 42” models
47-1/2” for 48” models
90° Door Swing130° Door Swing
*Finished Width
6"
5"
Electrical
Area
84 1/2" max
83 1/2" min
Finished
Opening
75" From Flo
to Bottom
of Electrica
l
Area
24"
5"
5"
3 1/2"
Water Supply
3 1/2"
36" Models 1
2
42" Models 1
8
48" Models 2
0
$OORZPLQLPXPFOHDUDQFHVIRUWKHIUHH]HUGRRU
'LPHQVLRQ$DQGIUHVKIRRGGRRU'LPHQVLRQ%
for a full 130° door swing and to allow for pan removal.
)RUDGRRUVZLQJDOORZµPLQFOHDUDQFHWRDZDOO
IRUIUDPHGDQGVWDLQOHVVVWHHOPRGHOV$OORZµPLQ
clearance for professional series models. If the 90° door
stop position is used, pan access is maintained, but pan
removal is restricted.
See the illustrations on pages 4 and 5 to determine door
swing interaction with adjacent cabinets or countertops.
Models A B C
36” 13” 15” 20-5/8”
42” 13” 19” 26-5/8”
48” 15” 20” 28-5/8”
*84" From
Floor to
Top Frame
25-3/8" Framed Models
25-3/4" Stainless Steel Models
Depth Including Handles:
26-7/8" Framed Models
27-3/4" Stainless Steel Models
28-11/16" Professional Models
36", 42" or 48"
Frame to Frame
35", 41", or 47"
Case Width
*83-1/2"
at
Rear
23-7/8"
Behind
Frame
C
90 Door Swing
*Min. Distance
to Wall
*4” Stainless and
Trimmed Models.
5” Pro Series
