Monsoon Multimedia HAVA Titanium - COMPOSITE CABLE CONNECTION; S-VIDEO CONNECTION

10-2007
Page 4 of 7
COMPOSITE CABLE CONNECTION:
Use the included Composite Cable to connect one end from the available outputs on your Cable/Satellite
box to the inputs labeled “A/V In” on your HAVA unit
Composite Cable Cable Set-Top/Satellite/DVR Box
HAVA Device
Yellow = Video
Red = Audio Right
White = Audio Left
Connect to video source
Connect to TV (if needed)
Pass-through Connection
S-VIDEO CONNECTION:
