outside or angle of the side of the boat. The Heim joint has three purposes. First, it
allows the base to mount if your boat has a slight angle at the mounting areas. Second,
it allows the rear legs to rotate so the tower can fold down for storage. Third, the Heim
joint prevents any of the lateral (side to side) movement of the tower from causing
stress to the boat. You are now an expert on the Parts of the Monster Tower and we will
use the terminology of the Parts List throughout this document. Note that Parts refer to
components of the tower and Items refer to hardware, tools and accessories.
Monster Tower Hardware List
Item
Metric Dimension
Equivalent
Connection
Qty
Inch Dimensions
1
M8 x 60 SHCS / Washer / Nylock
5/16-18 x 2"
Base to boat
8
2
M12 x 85 SHCS / Washer / Nylock
1/2-13 x 3-1/2"
Base to base swivel
4
3
M12 x 35 SHCS
1/2-13 x 1-3/8"
Attach rod end to base swivel
4
4
M12 Rod End Bearings (Heim Joint)
1/2" Rod End Bearing
Base swivel to rod end support
4
5
M12 Flat Hex Nut
1/2" Hex Jam Nut
Jam nut for rod end
4
6
M12 x 75 SHCS / Washers / Nylock
1/2" x 3"
Front Leg swivels to top section
2
7
M12 x 12 Set Screw (preinstalled)
3/8" x 1/2"
Lock rear swivel in collar
4
8
3" x 2" Metal Backing Plate
3" x 2"
Backing plate for under deck
4
9
Monster Paw Backing Pads
3" x 2"
Pads to boat mounts
8
10
2-1/2” Teflon Fender Washer
Front Legs & Top Section Swivel
2
11
M6 Head Allen Wrench
For M8 Bolts
Supplied tool
1
12
M8 Head Allen Wrench
For M10 Bolts
Supplied tool
1
13
M10 Head Allen Wrench
For M12 Bolts
Supplied tool
1
14
Foil Packet of Anti-Seize Lubricant
This is critical to use on all bolt threads to prevent galling.
15
M8 x 55 SHCS / Washers / Nylock
5/16” x 2”
Rear swivel / Leg Anchors
4
16
M12 Quick Release Knobs
M12 x 35 – Item 3
Supplied Hardware
2
17
M10 x 55 SHCS / Washers / Nylock
3/8” x 2”
Rear Leg to top section
2
18
Spare Parts-Item:#1(x2),#2,#6,#7,#17
SHCS - Socket Head Cap Screw (Bolt)
Nylock - Nut with built in locking ring
The above hardware and tools are included with your Monster Tower and are
referenced to in the installation of the tower by their item number.
Items and tools needed for Installation
The following items will be needed for the installation of the tower and are not
supplied.
Required
Optional
Reversible Drill & 1/8”, 1/4”, 5/16”, 3/8” & 1/2" Drill Bits
Adjustable wrench or 13mm & 19mm metric sockets
Torque Wrench (no pneumatic wrenchs)
Any general purpose grease for Front Leg Swivels
Masking Tape, Tape Measure & Pencil
Friend to help hold & hand things
Safety Glasses (always use when drilling fiberglass or metal)
Vacuum for drill shavings
Throw tarps (to cover boat)
1/4” or 3/8” PT Plywood
Silicone Sealant
Loctite removable threadlock
(In place of anti-seize)
Layout and Planning
