DES-192
REV 1.0
12”
Measure out 12” on both the front left and right
sides starting from the center of the front header.
Make a mark.
Center the swivel mount on the
measurement. Mount should be sloping
downward slightly. The THREADED SIDE
FACES UP. Repeat for both sides.
Hardware Needed:
1. 2.
5
Step 3: Installing Front Header Hardware
Step 4: Securing Bimini Canvas Top to Tower
Unfold the bimini and place it over
the tower, making sure the tow point
goes through the hole in the canvas.
1.
