11. “Line and Neutral OK” Indicator: Indicates the wall outlet’s L-N line that the Monster AVS 2000 is plugged
into is properly wired.
12. Switched Outlets: Power is delivered to these outlets only when the Monster AVS 2000 is on.
13. Unswitched Outlets: Power is delivered to these outlets even when the Monster AVS 2000 is off.
14. Outlet Programming: Determines the delay time associated with the switched outlets.
15. Resettable 15 Amp Circuit Breaker: Protects the Monster AVS 2000 from continuous power overload.
16. Remote “DC In” Control: Allows you to automatically turn on the Monster AVS 2000 via the Remote “DC Out”
on another component, such as an AV receiver.
17. Remote “DC Out” Control: Allows you to turn a remote device on automatically when the Monster AVS 2000
is turned on.
18. Ground Screw: Provides a ground reference point for any ungrounded component.
