| Manuale d’istruzioni | Serie FIRE PASSIVE MK210
Dati Tecnici
Curva di risposta
ENCLOSURE 2-way bass-reflex.
COMPONENTS Custom-designed to Montarbo
®
specifications.
LF 1 x 12" woofer (2.5" voice coil).
HF 1 x compression driver (1" throat, 1.4" voice coil).
Constant directivity horn(80° H x 60° V).
FREQUENCY RESPONSE 60 Hz ÷ 20 kHz
SENSITIVITY 98 dB SPL @ 1 W / 1 m
CONTINUOUS SPL 124 dB
CROSS-OVER FREQUENCY 2.0 kHz
IMPEDANCE 8 Ω
NOMINAL POWER 400 W AES
POWER HANDLING 800 W peak
CONNECTIONS 2x Neutrik
®
speakON
®
CONSTRUCTION birch plywood, 15/10 steel protection grille with foam.
FITTINGS Carrying handle, speaker-stand adapter, 7 x 10MA hanging points
DIMENSIONS W 366 x H 580 x D 365 mm
WEIGHT 19 kg
