| Manuale d’istruzioni | Serie FIRE PASSIVE MK26
Dati Tecnici
Curva di risposta
ENCLOSURE 2-way bass-reflex.
COMPONENTS Custom-designed to Montarbo
®
specifications.
LF 1 x 10" woofer (2.5" voice coil).
HF 1 x compression driver (1" throat, 1.4" voice coil).
Constant directivity horn (80° H x 60° V).
FREQUENCY RESPONSE 65 Hz ÷ 20 kHz
SENSITIVITY 96 dB SPL @ 1 W / 1 m
CONTINUOUS SPL 122 dB
CROSS-OVER FREQUENCY 2.0 kHz
IMPEDANCE 8 Ω
NOMINAL POWER 400 W AES
POWER HANDLING 800 W peak
CONNECTIONS 2x Neutrik
®
speakON
®
CONSTRUCTION birch plywood, 15/10 steel protection grille with foam.
FITTINGS Carrying handle, speaker-stand adapter, 7 x 10MA hanging points
DIMENSIONS W 325 x H 515 x D 350 mm
WEIGHT 16.7 kg
