Montarbo T18A User Manual

T18A / T15A / T12A 3-way, bi-amplified, active loudspeaker systems
Specifications
Technical specifications
Enclosure
• Components:
- bass frequencies
Nominal diameter
Nominal impedance
Frequency range
Power capacity
Sensitivity
Net weight
Thiele & Small Parameters
fs
Re
Qms
Qes
Qts
Vas
B.l
SD
X max
Mms
Le
- mid frequencies
Nominal diameter
Nominal impedance
Frequency range
Power capacity
Sensitivity
Voice coil diameter
winding material
Voice coil former
Net weight
Thiele & Small Parameters
fs
Re
Qms
Qes
Qts
Vas
B.l
SD
Xmax
Mms
Le
- high frequencies
- Exponential horn
Nominal coverage:
Cutoff frequency:
Throat diameter:
- Driver
Throat diameter:
Nominal impedance:
DC resistance:
Power capacity:
Sensitivity:
Frequency range:
Recommended crossover:
Voice coil diameter:
Winding material:
Inductance:
Flux density:
Overall diameter:
Depth:
Net weight:
Diaphragm material
• Impedance
• Frequency response
• Electronic crossover
• Sensitivity (1W / 1m)
• Max SPL
Built-in power amplifiers
• Max. output power
bass
mid-high
• Frequency response
• Input impedance and sensitivity:
• Noise referred to input
• Power supply
Connections
Construction
Dimensions (wxhxd) / Weight:
T12A
3-way vented box, low turbolence ports
custom designed to Montarbo specs
12" neodymium magnet loudspeaker
12"
8 Ohms
48÷5000Hz
700W
101dB
2,7 Kg
46Hz
5,7 Ohms
2,5
0,26
0,25
91dm
3
17,3T/m
522cm
2
±4mm
43gr
1,5mH
6" midrange
6"
8 Ohms
150÷6000Hz
240W
97dB
38,5mm
alluminium
kapton
2,2 kg
130Hz
5,7 Ohms
3,7
0,49
0,44
3dm
3
10,5T/m
132cm
2
±2mm
12gr
0,25mH
1" compression driver loaded by a
90° x 70° horn
(HxV) 90° x 70°
1200Hz
1"
1"
8 Ohms
6,2 Ohms
120 W
108,5dB
1÷20 kHz
1,2kHz; 12dB/oct
44 mm
aluminium
0,11mH
1,85T
120 mm
62mm
2,1 kg
polyimide
8 ohms
45 Hz ÷ 20 kHz
- bass: 45Hz ÷ 600 Hz
- mid: 600Hz ÷ 3,5kHz
- high: 3,5kHz ÷ 20 kHz
600 Hz, 24dB/octave (Linkwitz-Riley)
101 dB SPL 1W, 1m
129 dB
2, MosFet (class AB) / 2 processors
500 W continuous / 670 W peak
350 W cont. (8Ohms / 0.1%THD) / 450 W peak
150 W cont. (8Ohms / 0.1%THD) / 220 W peak
10Hz ÷ 40kHz ±1dB
0dB / 10k Ohms
-110dB (A weighted)
230 V.A.C. 50÷60 Hz / fuse: T 3,15 AL
on request 117 V.A.C. 50÷60Hz (fuse: T 6,3 AL)
Neutrik Combo
®
(combined XLR + jack)
for input; XLR for the Link Output.
Multiply birch; polyurethane paint;
powder coated steel protection grille;
carrying handles; stand adaptor.
42 x 61,6 x 35 cm / 19 kg
APPENDIX
12
T15A
3-way vented box, low turbolence ports
custom designed to Montarbo specs
15" neodymium magnet loudspeaker
15"
8 Ohms
40÷3,800Hz
700W
102dB
3,5 Kg
39Hz
5,4 Ohms
4
0,32
0,29
194dm
3
19,2T/m
855cm
2
±5mm
88gr
1,7mH
6" midrange
6"
8 Ohms
150÷6000Hz
240W
97dB
38,5mm
alluminium
kapton
2,2 kg
130Hz
5,7 Ohms
3,7
0,49
0,44
3dm
3
10,5T/m
132cm
2
±2mm
12gr
0,25mH
1" compression driver loaded by a
90° x 70° horn
(HxV) 90° x 70°
1200Hz
1"
1"
8 Ohms
6,2 Ohms
120 W
108,5dB
1÷20 kHz
1,2kHz; 12dB/oct
44 mm
aluminium
0,11mH
1,85T
120 mm
62mm
2,1 kg
polyimide
8 ohms
40 Hz ÷ 20 kHz
- bass: 40Hz ÷ 600 Hz
- mid: 600Hz ÷ 3,5kHz
- high: 3,5kHz ÷ 20 kHz
600 Hz, 24dB/octave (Linkwitz-Riley)
102 dB SPL 1W, 1m
130 dB
2, MosFet (class AB) / 2 processors
500 W continuous / 670 W peak
350 W cont. (8Ohms / 0.1%THD) / 450 W peak
150 W cont. (8Ohms / 0.1%THD) / 220 W peak
10Hz ÷ 40kHz ±1dB
0dB / 10k Ohms
-110dB (A weighted)
230 V.A.C. 50÷60 Hz / fuse: T 3,15 AL
on request 117 V.A.C. 50÷60Hz (fuse: T 6,3 AL)
Neutrik Combo
®
(combined XLR + jack)
for input; XLR for the Link Output.
Multiply birch; polyurethane paint;
powder coated steel protection grille;
carrying handles; stand adaptor.
45 x 72,6 x 40 cm / 24 kg
T18A
3-way vented box, low turbolence ports
custom designed to Montarbo specs
18" neodymium magnet loudspeaker
18"
8 Ohms
20÷1,000Hz
1000W
101dB
6,2 Kg
41Hz
5,6 Ohms
27,39
0,36
0,36
174,15dm
3
25,4T/m
1164cm
2
±6,75mm
159gr
0,85mH
8" midrange
8"
8 Ohms
150÷6000Hz
400W
98dB
50mm
alluminium
kapton
3,4 kg
75,7Hz
6,07 Ohms
4,83
0,36
0,34
17,56dm
3
12,08T/m
227cm
2
±6,25mm
18,2gr
0,46mH
1" compression driver loaded by a
90° x 70° horn
(HxV) 90° x 70°
1200Hz
1"
1"
8 Ohms
6,2 Ohms
120 W
108,5dB
1÷20 kHz
1,2kHz; 12dB/oct
44 mm
aluminium
0,11mH
1,85T
120 mm
62mm
2,1 kg
polyimide
8 ohms
38 Hz ÷ 20 kHz
- bass: 38Hz ÷ 280 Hz
- mid: 280Hz ÷ 1,3kHz
- high: 1,3kHz ÷ 20 kHz
280 Hz, 24dB/octave (Linkwitz-Riley)
102 dB SPL 1W, 1m
130 dB
2, MosFet (class AB) / 2 processors
500 W continuous / 670 W peak
350 W cont. (8Ohms / 0.1%THD) / 450 W peak
150 W cont. (8Ohms / 0.1%THD) / 220 W peak
10Hz ÷ 40kHz ±1dB
0dB / 10k Ohms
-110dB (A weighted)
230 V.A.C. 50÷60 Hz / fuse: T 3,15 AL
on request 117 V.A.C. 50÷60Hz (fuse: T 6,3 AL)
Neutrik Combo
®
(combined XLR + jack)
for input; XLR for the Link Output.
Multiply birch; polyurethane paint;
powder coated steel protection grille;
carrying handles; stand adaptor.
52 x 78 x 41 cm / 35 kg
