Montarbo T18A User Manual

3-way, bi-amplified, active loudspeaker systems T18A / T15A / T12A
Note: the balanced input can accept also unbalanced connectors
(automatic unbalancing)
Nota: l'ingresso bilanciato accetta anche connettori sbilanciati
(sbilanciamento automatico).
Hinweis: der symmetrische Eingang akzeptiert auch unsymmetrische Verbinder
(automatische Unsymmetrie)
Note: il est aussi possible d’adapter des connecteurs non symétriques à l’entrée
symétrique (ils deviennent asymétriques automatiquement)
Nota: la entrada balanceada puede aceptar también conectores no balanceados
(desbalanceo automático).
BALANCED XLR
MALE CONNECTOR
BALANCED
JACK CONNECTOR
▲
▲
▲
▲
BALANCED
XLR + JACK
SOCKET
▲
▲
BALANCED XLR
MALE SOCKET
BALANCED XLR
FEMALE CONNECTOR
Connectors
1 GND Ground
2 + Hot
3 - Cold
(IEC 268 standard)
15
APPENDIX
