Montech AIR 1000 Series User Manual

Air 1000
EN
Colours
Black/White
Dimensions
416×220×490 mm
Motherboard Support
ATX/Micro ATX/Mini ITX
Expansion Slots/PCI
7
Drive Bays
4× 2.5” SDD or 2× 3.5” HDD
2× 2.5” SSD
I/O Ports
1× USB 2.0, 2× USB 3.0, Microphone, Headset, LED button
Pre-installed fans
3× Lite 120mm (high airow fan)
3× Silent 120mm (high airow fan)
3× Premium 140mm/1× 120mm (ARGB fan)
Positions for fans
Front: 3× 120 mm/3× 140 mm
Rear: 1× 120 mm
Inside: 2× 120 mm
Top: 2× 120/140 mm
Radiator support
Front: 120/140/240/280/360 mm
Rear: 120 mm
Top: 120/140/240/280 mm
Clearances
VGA: 340 mm
CPU: 165 mm
Dust lters
Front, Top, Bottom
Power supply support
Bottom mount, ATX

Montech AIR 1000 Series Specifications

General

Type	Mid Tower
Expansion Slots	7
Color	Black, White
Motherboard Support	ATX, Micro-ATX, Mini-ITX
Material	Steel, Tempered Glass
Cooling Support	Front: 120mm
Radiator Support	Rear: 120mm
Drive Bays	2 x 3.5"
Front I/O Ports	Audio
Maximum PSU Length	180mm
Pre-installed Fans	Front: 120mm
