MOODY Eclipse 38 - Page 26

Moody 35
STAY
FORESTAY
INNER
FORESTAY
CAP SHROUD
INTERMEDIATE
FORWARD
LOWER
AFT LOWER
BACKSTAY
QTYPERSET
1
0
2
2
2
2
1
TOP END
FITTING
Eye swaged
-
Shroud
Shroud
Shroud
Shroud
Eye swaged
BOTTOM END
FITTING
Rigging screw
-
Rigging screw and
roller
Rigging screw and
roller
Rigging screw and
roller
Rigging screw and
roller
Rigging screw and
roller
OVERALL
LENGTH (M)
13.275
0
12.6
9.01
5.095
5.0
14.105
Moody 376
STAY
FORESTAY
INNER
FORESTAY
CAP SHROUD
INTERMEDIATE
FORWARD
LOWER
AFT LOWER
BACKSTAY
QTYPERSET
0
1
2
2
0
2
1
TOP END
FITTING
-
Shroud
Shroud
Shroud
-
Shroud
Eye swaged
BOTTOM END
FITTING
-
Rigging screw and
roller
Rigging screw and
roller
Rigging screw
-
Rigging screw
Rigging screw
OVERALL
LENGTH (M)
0
4.58
14.07
9.52
0
4.9
15.445
Issue 3
Page 2.3
