MOODY Eclipse 38 - Page 73

Battery isolation switch
ENGINE
Starter
BAT 1
Battery status meter
Select switch
BAT 2
BUSS BAR
Skin fittings
(prop, seacocks etc)
-• Steaming light
-• Deck light
-• Navigation lights
-• Spare
—• Cabin lights
Bunk lights
/shaver
Engine room
~* light
Freshwater
-|-«pump«
Fridge
•o-
1
Navigation instruments
' Wipers
Accessories
Compass light
Spare
Spare
