Mooer GE250 - Back Panel Connectivity; Audio and Expression I;O Ports; Digital, MIDI, and Power Connections; XLR Output and Grounding

USB
IN
AUXIN
L(MONO)
R
EXP2
DC9V
1A
MIDIIN/
MIDIOUT
SEND RETURN
R
L(MONO)
FXLOOP XLROUT OUTPUT
01 02 03 04 05 06 07 08
BackPanel
AUXIN:1/8''stereojacktoconnectexternalmediadevicesforaudioplayback.
EXP2:¼''stereojack/externalexpressionpedalinput.
IN:Instrumentinput.
¼''monojackwithGuitar/Linelevelswitch.
SEND:1/4''FXLOOP.Canconnectextrastompboxes,4-cablemethodwithamplifier.
RETURN:1/4''FXLOOP.Canconnectextrastompboxes,4-cablemethodwithamplifier.
XLROUT:XLRbalancedoutput.
GND/LIFTswitch:GroundingswitchforXLRoutput.
OUTPUT:1/4''L/Runbalancedoutput.
PHONES:Dedicatedheadphoneoutput.1/8”stereojack.
MIDIIN/OUT:MIDIportsforMIDIIN/OUT.
USB:USBType-Bporttoconnecttodirectrecorddigitalaudio.
InterfacewithofficialMOOERsoftwaretoeditandimport/exportpresetsandupdatefirmware.
I/O:PowerON/OFFswitch.
DCIN:ConnectGE250powersupply.
CableTidy:Loopthecablefromyourpowersupplytoavoidaccidentaldisconnection.
