INPUT:1/4” mono audio jack for connecting instrument
OUTPUT:Audio output 1/4” mono audio jack
AUX IN:Stereo line in for connection to external devices such as mp3
player for audio playback.
HEADPHONES: Stereo line out for connecting to a headset or other
external audio equipment
DC IN:Connects to the supplied power adaptor(DC 9V, 300mA, )
Master Volume: Adjusts the master output volume of the device
Battery hatch: Insert 2 x AAA batteries for battery operation
10 11 12 13 14
15
16
Portable Guitar Effcts
:ART N
O
PE1
00
Adapter:
9V,300mA
Polarity :
Remval of screws or the serial number
label will void warranty
