BACK PANEL LAYOUT
POWER: Toggles power on/off to the amplifier
01
AC IN: Connect 3 pin grounded AC power cord
02
POWER FUSE: Contains the main power protection fuse and a backup replacement fuse.
If the amplifier cannot power on, inspect the protection fuse and replace if necessary.
T500mA - 220V-240V
T1000mA- 100V-120V
03
AC VOLTAGE: Select correct setting for your current region. Please note that the correct
POWER FUSE must also be installed. DO NOT change this setting with a power cord
connected to your amplifier.
04
SPEAKER OUT: Connect to an external speaker with an impedance of 8Ω - 16Ω
05
EFFECTS LOOP : Easily integrate your favourite external effects by connecting them to
the effects loop
06
SEND – Effects send (preamp out) – Connect to the input of external effects
RETURN – Effects return (Power amp in) – Connect to the output of external effects
XLR OUT: Direct audio out with optional speaker cabinet simulation and ground lift
switch. For connection direct to PA or audio interface.
07
USB: Connect to computer for firmware updates
08
